Ordering code
Specification
| Bore(mm) | 6 | 10 | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 |
| Acting type | Double acting | |||||||||||
| Working medium | Air (To be filtered by 40μm filter element) | |||||||||||
| Protection against torsion/guide | Guide rod with yoke/with plain-bearing or ball bearing guide | |||||||||||
| Operating pressure | 1~10 Bar | |||||||||||
| Temperature range | ||||||||||||
| DFM-…-GF(℃) | -10~+60 | -20~+80 | ||||||||||
| DFM-…-KF(℃) | – | -5~+60 | ||||||||||
| Port size | M3 | M5 | G1/8 | G1/4 | G3/8 | |||||||
