Ordering code
Specification
| Model | MOV-01 | MOV-02 |
| Port size | 1/8“ | 1/4“ |
| Body material | Aluminium alloy | |
| Fluid | Compressed air | |
| Sectional area | 1.8mm2 | |
| Operating pressure range | 0 ~ 9 kgf/cm2 | |
| Max. operating pressure | 10 kgf/cm2 | |
| Ambient temperature | -10℃~60℃ | |
| Standard operator color | Black：TB, LB；Red：PB, PP, PPL, EB | |
MOV Dimension
