Ordering code
Specification
| Bore (mm) | 4 | 6 | 10 | 15 |
| Acting Type | Single acting / Double acting | |||
| Working Medium | Air (To be filtered by 40μm filter element) | |||
| Operating Pressure | 3~7 Bar | 2~7 Bar | 1.5~7 Bar | |
| Proof Pressure | 10 Bar | |||
| Temperature Range | -10~70℃ | |||
| Operating Speed Range | 50~500 mm/s | |||
| Cushion Type | No | |||
| Port Size(Panel mount type) | M3*0.5 | M5*0.8 | ||
