Ordering code
Specification
| Size | 4 | 5 | 7 | 8 | 10 | 12 | 16 | 20 | 25 | 32 |
| Stroke (mm) | 4 | 5 | 5 | 8 | 10 | 12 | 20 | 25 | 40 | 60 |
| Acting type | Hydraulic shock absorber with spring return | |||||||||
| Single-acting, pushing | ||||||||||
| Cushioning | Self-regulating,hard characteristic curve | |||||||||
| Cushioning length (mm) | 4 | 5 | 5 | 8 | 10 | 12 | 20 | 25 | 40 | 60 |
| Type of mounting | With lock nut | |||||||||
| Impact velocity (m/s) | 0.05~2 | 0.05~3 | ||||||||
| Ambient temperature (℃) | -10~+80 | |||||||||
