Ordering code
Specification
| Model | ZU05S | ZU05L | ZU07S | ZU07L |
| Fluid | Air | |||
| Ambient temperature | 5~60℃ | |||
| Max. operating pressure | 6 Bar | |||
| Standard supply pressure | 4.5 Bar | |||
| Tube O.D. | 6mm | |||
| Air consumption(L/min) | 14 | 14 | 29 | 29 |
| Max. vacuum pressure(kPa) | -85 | -48 | -85 | -48 |
Dimension
