Ordering Code
Specification
| Model | CV-06 | CV-08 | CV-10 | CV-15 | CV-20 | CV-25 |
| Port size | 1/8“ | 1/4“ | 3/8“ | 1/2“ | 3/4“ | 1″ |
| Fluid | Compressed air | |||||
| Body Material | Aluminum alloy / Brass | |||||
| Operating pressure range | 0.05~1 MPa | |||||
| Ambient temperature | -10℃~80℃ | |||||
CV Dimension
| Model | CV-06 | CV-08 | CV-10 | CV-15 |
| R | 1/8″ | 1/4″ | 3/8″ | 1/2″ |
| A | 36.5 | 40.5 | 40.5 | 51 |
| B | 12.5 | 16 | 19 | 24.2 |
