Ordering code
Specification
| Model | VF3130 | VF3230 | VF33(4/5)30 | VF5120 | VF5220 | VF53(4/5)20 |
| Valve type | 5 port 2 position | 5 port 3 position | 5 port 2 position | 5 port 3 position | ||
| Orifice size | 16mm² （Cv=0.89） |
12mm（Cv=0.67） | 25mm² （Cv=1.40） |
18mm（Cv=1.00） | ||
| Fluid | Air(to be filtered by 40μm filter element) | |||||
| Acting | Internal pilot | |||||
| Operating pressure | 0.15~0.8MPa | |||||
| Proof pressure | 1.2MPa（175psi） | |||||
| Temperature | -20~70℃ | |||||
| Operating Voltage Tolerance | ±10% | |||||
| Apparent power | AC: 5.5VA DC: 4.8W | |||||
| Insulation and Protection class | F Class. IP65 | |||||
| Wiring form | Grommet or Terminal type | |||||
| Max. operating frequency | 5 cycle/sec | |||||
| Shortest excitation time | 0.05s | |||||
VF Dimension
